Material:Stainless steel, galvanized steel, carbon steel
Strength Grade:4.8, 6.8, 8.8, 10.9, 12.9
Surface Treatment：HDG, plain, black oxide, galvanized
Size:M3-M100
DIN 933 bolt is a full threaded hexagon head bolt, which means that it has a six-sided head and threads extending the entire shaft.
Jingtong company provide all kinds of fasteners with DIN standard, for instance, bolts, screws, nuts, washers, pins, which are widely used in machinery manufacturing, construction engineering, automotive parts, electrical installation and equipment assembly. DIN (Deutsches Institut für Normung) standard is a German industrial standard with strict size, tolerance, performance and quality requirements, suitable for international engineering projects.
The main DIN standards for fastener include:
1. DIN 933: Full-threaded Hexagon bolts
2. DIN 931: Half-threaded Hexagon bolts
3. DIN 934: Hexagon nuts
4. DIN 912: Hexagon socket head screws
5. DIN 7981 / 7982: Self-tapping screws
6. DIN 125 / DIN 127: Flat washers and spring washers
7. DIN 965 / 966: Cross recessed countersunk screws
Product name | DIN933 Full Thread Hexagon Bolt |
Other name | Hexagon Bolt |
Standard | DIN933 |
Size | M3-M100 |
Material | Stainless steel, galvanized steel, carbon steel |
Strength Grade | 4.8, 6.8, 8.8, 10.9, 12.9 |
Surface treatment | HDG, plain, black oxide, galvanized |
Packaging Details | Cartons + pallets, or as your required |
The Size and Weight Chart of DIN933 Full Thread Hexagon Bolt
size | M8 | M10 | M12 | M14 | M16 | M18 | M20 | M22 | M24 |
Shank Diameter (mm) | 8 | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 |
Threaded Length (mm) | Weight of 1000 pcs / KG | ||||||||
8 | 8.55 | 17.2 | - | - | - | - | - | - | |
10 | 9.1 | 18.2 | 25.8 | 38 | - | - | - | - | - |
12 | 9.8 | 19.2 | 27.4 | 40 | 52.9 | - | - | - | - |
16 | 11.1 | 21.2 | 30.2 | 44 | 58.3 | 82.7 | 107 | 133 | 173 |
20 | 12.3 | 23.2 | 33 | 48 | 63.5 | 87.9 | 116 | 143 | 184 |
25 | 13.9 | 25.7 | 36.6 | 53 | 70.2 | 96.5 | 126 | 155 | 199 |
30 | 15.5 | 28.2 | 40.2 | 57.9 | 76.9 | 105 | 136 | 168 | 214 |
35 | 17.1 | 30.7 | 43.8 | 62.9 | 83.5 | 113 | 147 | 181 | 229 |
40 | 18.7 | 33.2 | 47.4 | 67.9 | 90.2 | 121 | 157 | 193 | 244 |
45 | 20.3 | 35.7 | 51 | 72.9 | 97.1 | 129 | 167 | 206 | 259 |
50 | 21.8 | 38.2 | 54.5 | 77.9 | 103 | 137 | 178 | 219 | 274 |
55 | 23.4 | 40.7 | 58.1 | 82.9 | 110 | 146 | 188 | 232 | 289 |
60 | 25 | 43.3 | 61.7 | 87.8 | 117 | 154 | 199 | 244 | 304 |
65 | 26.6 | 45.8 | 65.3 | 92.8 | 123 | 162 | 209 | 257 | 319 |
70 | 28.2 | 48.8 | 68.9 | 97.8 | 130 | 170 | 219 | 269 | 334 |
75 | 29.8 | 50.8 | 72.5 | 102 | 137 | 178 | 229 | 282 | 348 |
80 | 31.4 | 53.3 | 76.1 | 107 | 144 | 187 | 240 | 295 | 363 |
90 | 34.6 | 58.3 | 83.3 | 117 | 157 | 203 | 260 | 321 | 393 |
100 | 37.7 | 63.3 | 90.5 | 127 | 170 | 219 | 281 | 346 | 423 |
110 | 40.9 | 68.4 | 97.7 | 137 | 184 | 236 | 302 | 371 | 453 |
120 | - | 73.4 | 105 | 147 | 197 | 252 | 322 | 397 | 483 |
130 | - | 78.4 | 112 | 157 | 210 | 269 | 343 | 421 | 513 |
140 | - | 83.4 | 119 | 167 | 224 | 255 | 364 | 448 | 543 |
150 | - | 88.4 | 126 | 177 | 237 | 301 | 384 | 473 | 572 |
The Dimension Chart Of DIN933 Full Thread Hexagon Bolt
Size | M3 | M3.5 | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 | ||
d (mm) | 3 | 3.5 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | ||
P | Pitch | 0.5 | 0.6 | 0.7 | 0.8 | 1 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | |
a | max | 1.5 | 1.8 | 2.1 | 2.4 | 3 | 3 | 3.75 | 4.5 | 5.25 | 6 | 6 | |
c | min | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.2 | |
max | 0.4 | 0.4 | 0.4 | 0.5 | 0.5 | 0.5 | 0.6 | 0.6 | 0.6 | 0.6 | 0.8 | ||
da | max | 3.6 | 4.1 | 4.7 | 5.7 | 6.8 | 7.8 | 9.2 | 11.2 | 13.7 | 15.7 | 17.7 | |
dw | Grade A | min | 4.6 | 5.1 | 5.9 | 6.9 | 8.9 | 9.6 | 11.6 | 15.6 | 17.4 | 20.5 | 22.5 |
Grade B | min | - | - | 5.7 | 6.7 | 8.7 | 9.4 | 11.4 | 15.4 | 17.2 | 20.1 | 22 | |
e | Grade A | min | 6.01 | 6.58 | 7.66 | 8.79 | 11.05 | 12.12 | 14.38 | 18.9 | 21.1 | 24.49 | 26.75 |
Grade B | min | - | - | 7.5 | 8.63 | 10.89 | 11.94 | 14.2 | 18.72 | 20.88 | 23.91 | 26.17 | |
k | Nominal Size | 2 | 2.4 | 2.8 | 3.5 | 4 | 4.8 | 5.3 | 6.4 | 7.5 | 8.8 | 10 | |
Grade A | min | 1.88 | 2.28 | 2.68 | 3.35 | 3.85 | 4.65 | 5.15 | 6.22 | 7.32 | 8.62 | 9.82 | |
max | 2.12 | 2.52 | 2.92 | 3.65 | 4.15 | 4.95 | 5.45 | 6.56 | 7.68 | 8.98 | 10.18 | ||
Grade B | min | - | - | 2.6 | 3.26 | 3.76 | 4.56 | 5.06 | 6.11 | 7.21 | 8.51 | 9.71 | |
max | - | - | 3 | 3.74 | 4.24 | 5.04 | 5.54 | 6.69 | 7.79 | 9.09 | 10.29 | ||
k1 | min | 1.3 | 1.6 | 1.9 | 2.28 | 2.63 | 3.19 | 3.54 | 4.28 | 5.05 | 5.96 | 6.8 | |
r | min | 0.1 | 0.1 | 0.2 | 0.2 | 0.25 | 0.25 | 0.4 | 0.4 | 0.6 | 0.6 | 0.6 | |
s | max=nominal size | 5.5 | 6 | 7 | 8 | 10 | 11 | 13 | 17 | 19 | 22 | 24 | |
Grade A | min | 5.32 | 5.82 | 6.78 | 7.78 | 9.78 | 10.73 | 12.73 | 16.73 | 18.67 | 21.67 | 23.67 | |
Grade B | min | - | - | 6.64 | 7.64 | 9.64 | 10.57 | 12.57 | 16.57 | 18.48 | 21.16 | 23.16 | |
Size | M18 | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | ||
d (mm) | 18 | 20 | 22 | 24 | 27 | 30 | 33 | 36 | 39 | ||
P | Pitch | 2.5 | 2.5 | 2.5 | 3 | 3 | 3.5 | 3.5 | 4 | 4 | |
a | max | 42 | 46 | 50 | 54 | 60 | 66 | 72 | 78 | 84 | |
c | min | 48 | 52 | 56 | 60 | 66 | 72 | 78 | 84 | 90 | |
max | 61 | 65 | 69 | 73 | 79 | 85 | 91 | 97 | 103 | ||
da | max | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.3 | |
dw | Grade A | min | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 1 |
Grade B | min | 20.2 | 22.4 | 24.4 | 26.4 | 30.4 | 33.4 | 36.4 | 39.4 | 42.4 | |
e | Grade A | min | 18 | 20 | 22 | 24 | 27 | 30 | 33 | 36 | 39 |
Grade B | min | 17.73 | 19.67 | 21.67 | 23.67 | - | - | - | - | - | |
k | Nominal Size | 17.57 | 19.48 | 21.48 | 23.48 | 26.48 | 29.48 | 32.38 | 35.38 | 38.38 | |
Grade A | min | 25.3 | 28.2 | 30 | 33.6 | - | - | - | - | - | |
max | 24.8 | 27.7 | 29.5 | 33.2 | 38 | 42.7 | 46.6 | 51.1 | 55.9 | ||
Grade B | min | 30.14 | 33.53 | 35.72 | 39.98 | - | - | - | - | - | |
max | 29.56 | 32.95 | 35.03 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | ||
k1 | min | 11.5 | 12.5 | 14 | 15 | 17 | 18.7 | 21 | 22.5 | 25 | |
r | min | 11.28 | 12.28 | 13.78 | 14.78 | - | - | - | - | - | |
s | max=nominal size | 11.72 | 12.72 | 14.22 | 15.22 | - | - | - | - | - | |
We also provide non-standard bolts customization, OEM services, drawing processing, and have a complete quality management system for quality control.
